Industrial Freeze Dryer with 15 kg/batch Capacity Touch Screen Control and Steam Heating System

Industrial Freeze Dryer with 15 kg/batch Capacity Touch Screen Control and Steam Heating System

Nama merek:	LTPM China
Nomor Model:	LTDG-Seri
MOQ:	1 set
harga:	Dapat dinegosiasikan
Ketentuan Pembayaran:	L/C,T/T
Kemampuan Pasokan:	15 set/bulan

Informasi Detil

Deskripsi Produk

Informasi Detil

Tempat asal:

Cina

Sertifikasi:

Berat:

1200kgs

Nama Barang:

8000 Meter persegi/hari

Daerah Kering:

1,08 meter persegi

Daerah Baki:

1,02 meter persegi

Total Volume Dehidrasi:

15 kg/batang

Jarak Rak:

70mm

Modus Pemanasan:

Mode konduksi

Sistem Operasi:

Layar Sentuh

Kemasan rincian:

Kasus Kayu Standar Ekspor

Menyediakan kemampuan:

15 set/bulan

Menyoroti:

15 kg/batch Freeze Dryer

Touch Screen Lyophilizer

Steam Heating Vacuum Freeze Drying Equipment

Deskripsi Produk

Industrial Vacuum Food Freeze Drying Equipment

Designed for processing meat, fruits, vegetables, and beverages, the LTDG series freeze dryers from LTPMCHINA meet the growing demand for high-quality freeze-dried food products. These industrial-grade machines support mass production capacities from 200 to 2000 kg and feature steam heating systems for optimal performance.

System Configuration

The complete freeze drying system includes a freeze dryer chamber, blast freezer, and monorails system. Our flexible design approach ensures the equipment can be customized to fit specific client requirements and production environments.

Key Features

Economical design with high energy efficiency
Multiple heat source options: steam and electrical
Modular design for fast installation and short production cycles
Highly integrated components with compact footprint and reduced load requirements
Continuous automatic vacuum de-icing system with minimal temperature loss
Real-time precise temperature control for consistent product quality
Energy efficient operation with large freeze drying capacity
Rapid vacuum extraction reaching process requirements within 12 minutes
PLC automatic control system for optimal working conditions
Simple operation, easy maintenance, and reliable performance

Technical Specifications

Power	167Kw, 380V±10%, 50HZ, 3 Phase, 5 Wire
Vacuum Function	19.8kw
Refrigeration Function	92kw
Heating Function	55.5kw
Compressed Air	≥40L/min (P=0.5~0.8Mpa)
Cooling Water Quantity	≥50m³/h (T≤30℃, P=0.2-0.3Mpa)
Defrost Water Quantity	≥4000kg (T≥30℃, P=0.1-0.2Mpa)
Whole Volume	Dry chamber and Condenser: D=φ2100mm L=6650mm Freeze system vacuum system control system: L=2600mm W=2200mm H=2000mm Final dimension based on design
Structure	Split
Total Weight	15T (Approx.)

Equipment Components
