CE Certified High Efficiency Low Energy Consumption Food Lyophilization Equipment Freeze Dry Machine

CE Certified High Efficiency Low Energy Consumption Food Lyophilization Equipment Freeze Dry Machine

Nama merek:	LTPM China
Nomor Model:	LTDG-Seri
MOQ:	1 set
harga:	Dapat dinegosiasikan
Ketentuan Pembayaran:	L/C,T/T
Kemampuan Pasokan:	15 set/bulan

Informasi Detil

Deskripsi Produk

Informasi Detil

Tempat asal:

Cina

Sertifikasi:

Berat:

1200kgs

Nama Barang:

8000 Meter persegi/hari

Daerah Kering:

1,08 meter persegi

Daerah Baki:

1,02 meter persegi

Total Volume Dehidrasi:

15 kg/batang

Jarak Rak:

70mm

Modus Pemanasan:

Mode konduksi

Sistem Operasi:

Layar Sentuh

Kemasan rincian:

Kasus Kayu Standar Ekspor

Menyediakan kemampuan:

15 set/bulan

Menyoroti:

CE certified freeze dry machine

low energy consumption food lyophilizer

pharmaceutical freeze drying equipment

Deskripsi Produk

Vacuum freeze dryer is a processing equipment for heat and mass transfer of freeze-dried materials in a vacuum and low temperature environment. It is an interdisciplinary comprehensive technology. Freeze-drying requires technical support such as vacuum, refrigeration, heating, mechanical transmission, and automatic control. The application range of vacuum freeze-drying technology is very wide, as long as it is water-containing, non-corrosive substances can be made into freeze-dried products by freeze-drying technology, almost all agricultural and sideline products such as meat, poultry, eggs, aquatic products, vegetables, etc. Can be made into freeze-dried products. At present, freeze-drying technology is widely used in the food industry, biopharmaceutical industry, nanoscale materials, etc. The product processed by this technology is called freeze-dried food (fd food freeze-dried), which can maintain the color, aroma, taste, shape and nutritional components of the original food, and has a good rehydration effect.

Key Features

Economical design with high energy efficiency
Multiple heat source options: steam and electrical
Modular design for fast installation and short production cycles
Highly integrated components with compact footprint
Continuous automatic vacuum de-icing system with minimal temperature loss
Real-time precise temperature control for consistent product quality
Energy efficient operation with large freeze drying capacity
Rapid vacuum extraction reaching process requirements within 12 minutes
PLC automatic control system for optimal working conditions
Simple operation, easy maintenance, and reliable performance

Characteristics

Retain the original nutrition of the product
Dehydration thoroughly
Strong rehydration
Especially suitable for heat-sensitive substances

Application

Fruit
Vegetables
Pet food
Meat and Seafood
Condiments
Nutrition

Technical Specifications

Power	167Kw, 380V±10%, 50HZ, 3 Phase, 5 Wire
Vacuum Function	19.8kw
Refrigeration Function	92kw
Heating Function	55.5kw
Compressed Air	≥40L/min (P=0.5~0.8Mpa)
Cooling Water Quantity	≥50m³/h (T≤30℃, P=0.2-0.3Mpa)
Defrost Water Quantity	≥4000kg (T≥30℃, P=0.1-0.2Mpa)
Whole Volume	Dry chamber and Condenser: D=φ2100mm L=6650mm Freeze system vacuum system control system: L=2600mm W=2200mm H=2000mm Final dimension based on design
Structure	Split
Total Weight	15T (Approx.)
