Mesin Pengisian Dan Penyegelan Tabung Otomatis

Best Quality CE Approved High Speed New Design Hot Selling Automatic Soft Tube Filling and Sealing Tube Filling Machine

Best Quality CE Approved High Speed New Design Hot Selling Automatic Soft Tube Filling and Sealing Tube Filling Machine

Nama merek:	LTPM China
Nomor Model:	Seri LTRG
MOQ:	1set
harga:	Dapat dinegosiasikan
Ketentuan Pembayaran:	L/c, t/t
Kemampuan Penyediaan:	15Set/Bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

CINA

Sertifikasi:

Nilai otomatis:

Otomatis

Voltase:

380(220)V/50Hz

Bahan:

SUS 304/316L

Kapasitas produksi:

25-40 buah / mnt

Motor:

1.5kw

Tinggi tabung:

50-250mm

Berat:

300kg

dimensi (l*w*h):

1500*700*1800mm

Kemasan rincian:

Ekspor Kasing Kayu Standar

Menyediakan kemampuan:

15Set/Bulan

Menyoroti:

CE approved automatic tube filling machine

high speed tube sealing machine

soft tube filling and sealing equipment

Deskripsi Produk

Feature highlights

The Automatic Tube Filler and Sealer is designed for efficient filling and sealing of semi-fluid materials like cosmetics, beverages, and chemicals. With a capacity of 1800-3000 units/hour and adjustable filling accuracy up to 1%, it ensures reliable performance for manufacturing plants. Its compact dimensions (2440x900x2180mm) save space while the electric-driven system delivers energy-efficient operation. Engineers are available for overseas service, ensuring seamless integration and support. The machine's durable construction and user-friendly interface simplify maintenance and handling.

Features

Compact Design

Automatic Tube Loader Feeding Tubes

Driving Parts Fully-closed

Intelligent Temperature Control and Cooling System

Easy to Operate and Adjust

316L Stainless Steel Contact Parts to meet GMP Standard

Safety Interlock Shutdown when Door is Open

Overload Protection Provided

Automated Working process from Tube Loading to Finished Products Output

Automatic Orientation Effected by Photoelectric Induction

Chiller

Date Coding Embossing

Material level control system

Optional Devices

Change Parts For Different diameter tubes

Pneumatic plunger type material feeding pump

Heating and warm keeping function for hopper

Mixing function for hopper

Technical Parameters

Filling volume: 1-300ml/unit (Adjustable)

Filling accuracy:0.5%

Capacity:3600-4800unit/hour, Adjustable

Tube diameter: Φ12-60 mm

Tube length: 50-240 mm

Hopper volume: 40L

Power: 380/220V 50/60HZ, 3Phase

Air pressure: 0.4-0.6 MPa

Equipped motor: 1.1KW

Machine power: 5kw

Inner wind motor: 0.37kw

Convulsions motor: 0.37kw

Dimension: 2270×960×2100(mm)

Weight: About 1350 Kg
